126
EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual
Removal and Replacement Procedures (RRPs)
RRP: ED-DCX-4S-B chassis
This section describes how to remove and replace the ED-DCX-4S-B
chassis (with its backplane). The basic steps are:
1. “Verifying need for replacement”
2. “Recording critical ED-DCX-4S-B and SAN information”
3. “Disconnecting from the network and fabric”
4. “Removing components from the chassis”
5. “Installing the replacement chassis”
6. “Installing components into the new chassis”
7. “Verifying correct operation of system”
8. “Reconnecting the system to the network and fabric”
9. “Verifying correct configuration of the fabric”
Note: The ED-DCX-4S-B must be removed from the fabric and powered off to
perform this procedure. Contact your support provider if you have any
questions about whether the chassis requires replacement.
Time required
The chassis replacement takes approximately 3 hours.
Items required
The following items are required for the chassis replacement:
◆ Electrostatic discharge (ESD) grounding strap
◆ ESD grounding pads for protecting all blades and WWN cards
◆ Serial cable and workstation computer with a terminal emulator
application (such as HyperTerminal for Windows systems or TIP
for Solaris systems), required only if serial console session used
◆ Pallet jack or hydraulic or assisted lift that raises a minimum of 55
in. (140 cm) and carries a minimum of 250 lb (113 kg)
◆ A surface to place the old chassis on, such as a second lift or the
pallet originally provided with the old chassis
◆ #2 Phillips screwdriver
