EMC Connectrix B Series User Manual

RRP: ED-DCX-4S-B chassis
139
Removal and Replacement Procedures (RRPs)
• If the configuration information is not correct for the
ED-DCX-4S-B, modify as required. If necessary, the
configuration saved before the replacement can be
downloaded using the configDownload command.
The configDownload command can be entered through a
Telnet or serial session, but the ED-DCX-4S-B must have an
Ethernet connection to the server name or IP of the host for the
download process to complete. For more information, refer to
the help configdownload command or the EMC Connectrix B
Series Fabric OS Command Reference.
switch:admin> configdownload
Server Name or IP Address [host]: 123.123.123.123
User Name [None]: Admin24
File Name [config.txt]: config-switch.txt
Password: xxxxxxxx
download complete
switch:admin>
• If other issues exist, contact your support provider.
Cable routing table
Table 14 is a 48-port template for a cable-routing table. Expand the
table for the number of ports in the ED-DCX-4S-B.
Table 14 Cable routing table for ED-DCX-4S-B (48 ports shown) (page 1 of 3)
Slot/port Cable labels Connected device Slot/port of device
Slot Port Switch end Device end
0
1
2
3
4
5
6
7
8
9
