EMC Connectrix B Series v6.2 ED-DCX-4S-B Hardware Reference Manual

Installation

Items included with the ED-DCX-4S-B

The ED-DCX-4S-B ships with the following:

◆ ED-DCX-4S-B chassis, populated with:

• Control processor blades (CP8)

• Core switch blades (CR4S-8)

• Port blades, application blades, and encryption blades

(included based on customer specification)

• Blade slot filler panels (for slots not filled by blades)

• WWN cards

• WWN bezel (logo plate)

• Power supplies

• Power supply filler panel (included if there is only one power

supply)

• Blower assemblies

• Chassis door

◆ Accessory kit containing the following items:

• Cable management comb

• ESD grounding strap

•Port side exhaust kit

• RS-232 serial cable. The RS-232 cable has an adapter at one end

that can be removed to provide an RJ-45-style connector.

◆ ED-DCX-4S-B Rack mount kit with instructions

Order the optical transceivers (SFP and XFP) from EMC. The

ED-DCX-4S-B supports SWL, LWL, and ELWL transceivers.
