Port Side Exhaust Kit Installation Procedure
189
E
Air flows into the ED-DCX-4S-B through its non-port side and out
through the exhaust vent on the side of the unit, The Port-Side
Exhaust Mount Kit is designed to route this airflow out the exhaust
vents on the port side of the unit while mounted in the equipment
cabinet. This document provides instructions to install an
ED-DCX-4S-B in a 19 in. (48.26 cm) Electronic Industries Association
(EIA) cabinet using the following Brocade Port-Side Exhaust Mount
Kits:
• Kit for cabinet rail-to-rail depth of 27 to 31 in. (68.58 to 78.74
cm).
• Kit for cabinet rail-to-rail depth of 18 to 24 in. (45.72 to 60.96
cm).
◆ Safety.................................................................................................. 190
◆ Installation Guidelines .................................................................... 191
◆ Installing the ED-DCX-4S-B in Equipment Cabinet.................... 193
Port Side Exhaust Kit
Installation Procedure
To Next Page
