EMC Connectrix B Series User Manual

Port Numbering Template
181
D
Print or copy the following templates in this appendix and use them
to document the port numbering pattern for the ED-DCX-4S-B. These
templates show:
◆ Port side populated with four PB-DCX-48P port blades, two
CR4S-8 blades, and two CP8 blades
◆ Port side populated with four PB-DCX-32P port blades, two
CR4S-8 blades, and two CP8 blades
◆ Port side populated with four PB-DCX-16P port blades, two
CR4S-8 blades, and two CP8 blades
◆ PB-48K-10G-6 port blades
◆ PB-48K-18i application blades
◆ PB-48K-AP4-18 application blades
◆ PB-DCX-16EB encryption blades
The individual blades are shown vertically to make it easier to read
the port numbering. Their orientation in the DCX-4S chassis is
horizontal.
Port Numbering
Template
