Setting the IP addresses
49
Log In and Configuration
Setting the IP addresses
The ED-DCX-4S-B requires three IP addresses, which are configured
using the ipAddrSet command. IP addresses are required for both CP
blades (CP0 and CP1) and for the single logical switch (shown as
SWITCH under the ipAddrShow command) in the ED-DCX-4S-B.
Note: The default IP addresses and host names for the ED-DCX-4S-B are:
– 10.77.77.75 / CP0 (the CP blade in slot 4 at the time of configuration)
– 10.77.77.74 / CP1 (the CP blade in slot 5 at the time of configuration)
Note: Resetting an IP address while the ED-DCX-4S-B has active IP traffic or
has management and monitoring tools running, such as Fabric Manager,
Fabric Watch, and SNMP, can cause traffic to be interrupted or stopped.
1. Log in to the active CP as admin using the serial cable connection.
2. Set up the ED-DCX-4S-B IP address by entering the ipaddrset -sw
0 command:
swDir:admin> ipaddrset -chassis
Enter the information at the prompts. Specify the -sw 0 IP
address. There is no -sw 1 IP address.
Note: The addresses 10.0.0.0 through 10.0.0.255 are reserved and used
internally by the ED-DCX-4S-B. External IPs must not use these
addresses.
3. Set up the CP0 IP address by entering the ipaddrset -cp 0
command:
swDir:admin> ipAddrSet -cp 0
Enter the information at the prompts.
4. Set up the CP1 IP address by entering the ipaddrset -cp 1
command:
swDir:admin> ipAddrSet -cp 1
Enter the information at the prompts.
This is a sample IP configuration:
swDir:admin> ipaddrset -chassis
Ethernet IP Address [0.0.0.0]: 123.123.123.120
