RRP: ED-DCX-4S-B chassis
137
Removal and Replacement Procedures (RRPs)
Reconnecting the system to the network and fabric
See the cable routing information recorded in Table 14 on page 139
for the following steps.
1. Connect the CP blades to the local area network:
a. Insert the appropriate Ethernet cables into each Ethernet
port.
b. Connect the other ends to an Ethernet 10/100 Base-T LAN,
if not already connected.
Note: The ED-DCX-4S-B can be accessed by remote connection using any
of the available management tools, such as Telnet or Web Tools. Ensure
that the ED-DCX-4S-B is not modified using other connections during
the rest of this procedure.
2. Reconnect the transceivers and cables to the port blades:
Note: The ports and cables used in trunking groups must meet specific
requirements. For a list of these requirements, refer to the EMC
Connectrix B Series Fabric OS Administrator’s Guide.
a. Position one of the transceivers so that the key is oriented
correctly to the port and insert the transceiver into the port
until it is firmly seated and the latching mechanism clicks.
b. Select the cable that corresponds to the port and position it
so that the key (the ridge on one side of the cable
connector) is aligned with the slot in the transceiver; then,
insert the cable into the transceiver until the latching
mechanism clicks.
c. Repeat step a and step b for the remaining ports.
Note: Do not route cables in front of the air exhaust vent (located on
the upper port side of the chassis).
d. Organize the cables as required.
Verifying correct configuration of the fabric
Copying the command outputs from this section into a file is
recommended.
