Installing the ED-DCX-4S-B in Equipment Cabinet
203
Port Side Exhaust Kit Installation Procedure
Installing with 18-24 in. (45.72 to 60.96 cm) kit
Parts list
The parts list shown in Table 28 refers to items illustrated in Figure 44
on page 204.
Table 28 Hardware for Port-Side Exhaust Kit for 18-in. to 24 in. (45.72 to 60.96 cm)
cabinets
Item Description Quantity
ATop rail 1
B Top rail mounting brackets for 18-20 in., (45.72-50.8 cm) 20-22-in. (50.8-55.88 cm), and 22-24.in
(55.88-60.96 cm) cabinets
3
CDuct 1
D Shelf 1
E Shelf saddle 1
F 10-32 x .5 in. (1.27 cm) Phillips screw (blue Loctite on threads) 12
G 10-32 x .63 in.(1.60 cm) Phillips screw with square-cone washer 12
H 10-32 clip nut for cabinets that have rails with round holes 8
I 10-32 retainer nut for cabinets that have rails with square holes 8
J Alignment washer for cabinets that have rails with square holes 12
K 6-32 x .25 in. (.635 cm) Phillips screw 2
