RRP: ED-DCX-4S-B chassis
135
Removal and Replacement Procedures (RRPs)
The ED-DCX-4S-B performs a power-on self-test (POST). The
POST takes a minimum of three minutes and is complete when
LED activity returns to standard state.
12. Verify that the ED-DCX-4S-B is powered on and POST is
complete (all power LED indicators on the port, control processor,
and core switch blades should be a steady green).
13. Verify that all components are functioning correctly by checking
their LEDs. If the LEDs do not indicate correct operation, try
reinstalling the corresponding component.
Verifying correct operation of system
1. Log in to the ED-DCX-4S-B as admin:
switch:admin> login
login: admin
password: xxxxxxxx
switch:admin>
2. Enter slotShow command and verify that all the installed cards
are detected and that their status is operational (enabled).
switch:admin> slotShow
Slot Blade Type ID Status
---------------------------------
1 SW BLADE 55 ENABLED
2 UNKNOWN VACANT
3 CORE BLADE 52 ENABLED
4 CP BLADE 50 ENABLED
5 CP BLADE 50 ENABLED
6 CORE BLADE 52 ENABLED
7 UNKNOWN VACANT
8 SW BLADE 51 ENABLED
switch:admin>
3. Verify that the ED-DCX-4S-B is functioning correctly by typing
switchShow or switchStatusShow.
This switchShow command displays ED-DCX-4S-B and port
status information.
switch:admin> switchshow
switchName: switch
switchType: 62.1
switchState: Online
