Installing the ED-DCX-4S-B in Equipment Cabinet
193
Port Side Exhaust Kit Installation Procedure
Installing the ED-DCX-4S-B in Equipment Cabinet
Use the following instructions to install the ED-DCX-4S-B in an
equipment cabinet using the Port-Side Exhaust Kit.
Time required
Allow approximately one hour to unpack and install a chassis in a
cabinet.
Tools required
The following tools are required when installing the rack mount kit:
◆ Torque wrench with #2 Phillips screwdriver tip
◆ Flathead screwdriver
◆ Hydraulic or assisted lift with a minimum raise of 55 in. (140 cm)
and a minimum capacity of 250 lbs (113 kg).
Unpacking the Brocade DCX-4S
Follow the procedures in “Unpacking and installing the
ED-DCX-4S-B” on page 36.
Installing with 27 to 31 in. (68.58 to 78.74 cm) kit
Use the following procedures to install the ED-DCX-4S-B in a cabinet
with rail-to-rail depth of 27 to 31 in.(68.58 to 78.74 cm). Be sure to use
the 27-31 in. Port-Side Exhaust Kit for this installation.
Parts list
The following parts list refers to items illustrated in Figure 38 on
page 195.
