Maintenance 211
8
Reconnect all cables into the rear of the printer and turn on the printer.
Removing the Optional Font ROM
IMPORTANT:
• When you remove the optional Font ROM, be sure to turn off the printer, unplug the power cord, and disconnect all cables from the
rear of the printer before starting these tasks.
1
Turn off the printer.
IMPORTANT:
• Note that the data in the memory are cleared when the printer is turned off.
2
Turn the screw on the control board cover counterclockwise.
NOTE:
• Loosen the screw. You do not need to remove the screw.
3
Slide the control board cover towards the rear of the printer to remove the cover.
4
Pull the tabs on both sides of the font ROM outward to raise it.
To Next Page
