78 Printing Basics
Loading Print Media
Loading print media properly helps prevent jams and ensures trouble-free printing.
Before loading any print media, identify the recommended print side of the print media. This information is usually
indicated on the print media package.
Capacity
The standard 250 sheet tray and the optional 550 sheet feeder can hold:
• 250 sheets of the standard paper (standard 250 sheet tray).
• 550 sheets of the standard paper (optional 550 sheet feeder).
The bypass tray can hold:
• 50 sheets of the standard paper.
For special paper, there is a limitation of the following.
• From the bottom of the tray, up to 10 mm height (standard 250 sheet tray)
• From the bottom of the tray, up to 5.5 mm height (bypass tray)
Print Media Dimensions
The maximum dimensions of print media that the standard 250 sheet tray and the optional 550 sheet feeder can handle
are:
• Width: 139.7 mm (5.5 inches) to 215.9 mm (8.5 inches)
• Length: 210 mm (8.27 inches) to 355.6 mm (14 inches)
The maximum dimensions of print media that the bypass tray can handle are:
• Width: 76.2 mm (3 inches) to 215.9 mm (8.5 inches)
• Length: 127 mm (5 inches) to 355.6 mm (14 inches)
Loading Print Media in the Standard 250 Sheet Tray and the
Optional 550 Sheet Feeder
NOTE:
•
To avoid paper jams, do not remove the tray while printing is in progress.
• Use only laser print media. Do not use ink jet print media in your printer.
1
Pull the tray out of the printer about 200 mm.
