Basic Operation 27
Installing the Optional 550 Sheet Feeder
IMPORTANT:
•
If you install the optional 550 sheet feeder after setting up the printer, be sure to turn off the printer, unplug the power cord, and
disconnect all cables from the rear of the printer before installing the feeder.
1
Turn off the printer.
IMPORTANT:
• Note that the data in the memory are cleared when the printer is turned off.
2
Disconnect all cables from the rear of the printer.
3
Remove the tape and the bag holding the screws on the front of the optional 550 sheet feeder, and then remove the
screws from the bag.
4
Place the optional 550 sheet feeder in the location that the printer is located.
5
Gently pull open the bypass tray cover.
To Next Page
