5. NUMERIC/GRAPHIC DATA DISPLAY
5-2
5.2 Numeric, Graphic Data Description
When a data is lost its last-entered value is shown in red. Data displays can be turned
on or off through the [DATA DISPLAY] menu.
Numeric/
Graphic item
Description Display range
Available
formats
Where to change format
Heading Shows heading
input from head-
ing sensor.
32 comp. pts,
0°-359°
0°-359°
1°-179° P/S, 0°,
180°
32 comp. pts.
360° True
360° Rel
180° Rel
[Data Display] menu
Course Shows ship
course fed from
numeric/graphic
indication.
Speed Shows ship
speed fed from a
Numeric/graph-
ic indication.
0-40 kn Fixed at knots
Position of the
ship
Ship position in
latitude and lon-
gitude. If posi-
tion data is lost
the last-entered
position is
shown in red.
Lat: 90°00.000S-
90°00.000N Lon:
179°59.999W-
179°59.999E,
180°00.00
0°00.000
Lat/Lon
Position sen-
sor
The position
sensor type is
displayed in
brackets (“[]“).
When the posi-
tion sensor is not
connected, the
brackets are left
blank.
DGPS, KGPS, FGPS,
GPS, LC, DR, ***
Note: “***“ is dis-
played when the posi-
tioning error occurs.
GPS
Loran-C
DR
AUTO
System menu
Depth Shows depth
from transducer
to bottom.
0-9999 m Meters
Current Shows tide
speed and direc-
tion for three lay-
ers or tide and
speed for two
layers against a
reference layer
fed from a cur-
rent indication.
Cur. Speed: 0-9.9 kn
Direction: 0°-359°
Direction
shown as flow
from or flow to
[Current Vec & Wind]
menu
Net depth Depth of net
sonde transmit-
ter. Shown only
at shooting of
net.
0-999 m Depth of up to
3 pts can be
displayed.
[Net Sonde Setting] menu
