1. OPERATIONAL OVERVIEW
1-3
1.1.3 Remote controller (option)
The remote controller lets you control the sonar from a remote location.
Note: Keep the remote controller away from water and water splash. Hook the remote
controller to the bracket when it is not in use.
No. Function (on control unit)
1 Same as F1, F2 and F3 key.
2
Same as key.
3 Same as right-click button.
4 Same as the left-click button.
5
Same as [EVENT], [ESTI-
MATE], [TARGET LOCK] and
[FISH] keys.
6 Same as trackball.
7 Same as OFF CENTER key.
8 Same as USER PROG control.
9 Same as GAIN control.
10 Same as RANGE control.
11 Same as SHOOT key.
12 Records the current picture.
13 Shows the still image window.
14 Same as MODE key.
15 Same as AUTO TRAIN key.
16 Same as V1/S, V2 key.
17 Same as AUTO TILT key.
18 Same as TILT lever.
19 Same as H/V/S key.
