9. MAINTENANCE, TROUBLESHOOTING
9-9
9.11.2 Board test
The board test checks all the circuit boards in the system. Select [Board Test] from the
[Test] menu to do this test.
For any NG, contact your dealer for advice.
How to read the test results
(1)
Program no. (displayed in white). Abnormal number shown in red.
(2) TRX board update number (numbered from left)
“TRX70“ is displayed for 70 kHz.
(3) DIP switch setting on each board
(4) Memory read/write test results are shown as OK (white) or NG (red).
(5) +B voltage
(6) Motion sensor test results.
(7) Transducer temperature. Press the OFFCENTER key to display.
(8) No.2 control unit check.
BOARD TEST
MPU-001-FSV85 TRCPU-0
BMF-0
105- 0839-XX.XX
105-0830-XX.XX
105-0826-XX.XX
KO = MORKO = MAR
RAM = OK
TDS = OK
DATA = OK
RDS1 = OK
RDS2 = OK
FDS1 = OK
FDS2 = OK
Press MENU/ESC key to cancel.
INC
TRX80
TEST = OK
PITCH = +12.3
ROLL = - 2.5
PWR
12V = 12.2V
+B = 120.5V
䋱䋱䋱䋱䋱䋱䋱䋱䋱䋱䋱䋱䋱䋱䋱䋱
USB =
USB =
Monitor1 = 1280x1024
Monitor2 =
HDD = *****
PCI = *****
CPU Temperature = 32.0 C
BOARD Temperature = 20.0 C
CPU Fan Speed = 4800rpm
BATTRY = 3.2V
LAN MAC address = **-**-**-**-**-**
FSV-8501
105-0811-XX.XX
105-0812-XX.XX
105-0815-XX.XX
ROM = OK
RAM = OK
LAN MAC address = **-**-**-**-**-**
FSV-8501
105-0811-XX.XX
105-0812-XX.XX
105-0815-XX.XX
ROM = OK
RAM = OK
LAN MAC address = **-**-**-**-**-**
TD
TEMP = Under 60 C
S2 00000000䋨00䋩
S3 00000000䋨00䋩
S2 00000000䋨
40䋩
S3 00000000䋨00 䋩
S1 00000000䋨00䋩
S4 00000000䋨00䋩
S1 0000䋨0䋩
S1 0001䋨0䋩
FSV-8502
105-0818-XX.XX
105-0817-XX.XX
105-0816-XX.XX
S1 00000000䋨00䋩
ROM = OK
RAM = OK
LAN MAC address = **-**-**-**-**-**
S2 00000000䋨00䋩
OK: Normal, NG: Error
XX: Version No.
(1)
(2)
(3)
(4)
(5)
(8)
(6)
(7)
EWF = Enable
