8. RECORD/RECALL OPERATION
8-5
8.5 How to Load Files
8.5.1 How to load the setting information
This section shows you how to load the setting information saved at section 8.4.
1. Push the right-click button on the numeric/graphic data display to show the pop-
up menu.
2. Select [Record/Recall] then push the left-click button.
3. Select [Setting File] then push the left-click button.
4. Select [Load] then push the left-click button.
5. Select the file to load.
6. Select [Load] then push the left-click button.
The progress bar at the bottom of the box shows the loading progress. The [Set-
ting File] menu is appears when the saving is completed.
7. Long-press the MENU/ESC key to close all menus.
Progress bar
Destination list
To Next Page
Loading...
