5 CURRENT SETTING THRESHOLD SELECTION
The Phase Overcurrent protection threshold setting can be influenced by the Cold Load Pickup (CLP)and the
Voltage Dependent O
vercurrent (V DepOC) functions, should this functionality be used.
The Overcurrent function selects the threshold setting according to the following diagram:
Start
Does a Voltage Dependent
co
ndition exist?
End
Yes
No
V
00646
Use the threshold setting
ca
lculated by the Voltage
Dependent function
Does a cold Load Pickup
condition exist?
Yes
Use the current threshold setting
defined in the COLD LOAD
PICKUP column
Use the current threshold setting
de
fined in the OVERCURRENT
column
No
Figure 41: Selecting the current threshold setting
P14x Chapter 6 - Current Protection Functions
P14xEd1-TM-EN-1 109
