6.8 FIBRE OPTIC BOARD

Figure 21: Fibre optic board

This board pr

ovides an interface for communicating with a master station. This communication link can use all

compatible protocols (Courier, IEC 60870-5-103, MODBUS and DNP 3.0). It is a fibre-optic alternative to the metallic

RS485 port presented on the power supply terminal block. The metallic and fibre optic ports are mutually exclusive.

The fibre optic port uses BFOC 2.5 ST connectors.

The board comes in two varieties; one with an IRIG-B input and one without:

P14x Chapter 3 - Hardware Design

P14xEd1-TM-EN-1 51
