COMMUNICATIONS
RP1 Port Config
K-Bus
9. If using EIA(RS)485, the next cell (RP1 Comms Mode) selects the communication mode. The choice is either
IEC 60870 FT1.2 for normal operation with 11-bit modems, or 10-bit no parity. If using K-Bus this cell will not
appear
.
COMMUNICATIONS
RP1 Comms Mode
IEC 60870 FT1.2
10. If using EIA(RS)485, the next cell down controls the baud rate. Three baud rates are supported; 9600, 19200
and 38400. If using K-Bus this cell will not appear as the baud rate is fixed at 64 kbps.
COMMUNICATIONS
RP1 Baud rate
19200
7.2 IEC 60870-5-103
The specification IEC 60870-5-103 (Telecontrol Equipment and Systems Part 5 Section 103: Transmission
Protocols), defines the use of standar
ds IEC 60870-5-1 to IEC 60870-5-5, which were designed for communication
with protection equipment
This section describes how the IEC 60870-5-103 standard is applied to the Px40 platform. It is not a description of
the standard itself. The level at which this section is written assumes that the reader is already familiar with the
IEC 60870-5-103 standard.
This section should provide sufficient detail to enable understanding of the standard at a level required by most
users.
The IEC 60870-5-103 interface is a master/slave interface with the device as the slave device. The device conforms
to compatibility level 2, as defined in the IEC 60870-5-103.standard.
The following IEC 60870-5-103 facilities are supported by this interface:
● Initialization (reset)
● Time synchronization
● Event record extraction
● General interrogation
● Cyclic measurements
● General commands
● Disturbance record extraction
● Private codes
7.2.1 PHYSICAL CONNECTION AND LINK LAYER
Two connection options are available for IEC 60870-5-103:
● Rear P
ort 1 (RP1) - for permanent SCADA connection via RS485
● Optional fibre port (RP1 in slot A) - for permanent SCADA connection via optical fibre
P14x Chapter 18 - Communications
P14xEd1-TM-EN-1 415
