IED

E00500

TELECONTROL

LOGIC INPUT

AUTO

LOGIC INPUT

LIVE LINE

LOGIC INPUT

LIVE LINE

AUTO

NON AUTO

OPERATING MODES

LIVE LINE

AUTO

TELECONTROL

NON AUTO

4 POSITION SELECTOR SWITCH

MODE SETTINGS

AUTO COMMAND MODE

OPTO SET MODE

USER SET MODE

PULSE SET MODE

Figure 145: Four-position selector switch implementation

The required logic truth table for this arrangement is as follows:

Switch position AR Auto Mode Telecontrol Mode AR Live Line Mode

Non-auto 0 0 0

Telecontrol 0 or SCADA pulse 1 0

Auto 1 0 0

Live Line 0 0 1

Chapter 13 - Autoreclose P14x

288 P14xEd1-TM-EN-1
