2.3 Adjustment/operational checkout
2.3.1 Excitation adjustment
- Adjust the drive conditions of nozzles.
- This adjustment is performed in a state other than the IJ printer “ready” state.
- Be sure to perform this adjustment in the case of replacing the board (EZJ93, 94, 104),
the nozzle (including the print head) or changing the ink type.
In addition, when this adjustment is performed, be sure to carry out “2.3.4 Auto
phase gain adjustment.”
1 Press adjustment/operational checkout at the second page of the
service maintenance screen.
When the previous menu and the next menu are not displayed in the
maintenance menu, set to the service personnel maintenance mode by the
password protection.
With respect to the
password protection,
refer to "2.1 setting of
service personnel
maintenance mode".



Back
Status:XXXXXXXXX 2011.07.07 12:45Maintenance menu

Solenoid valve/
pump test
Adjustment/
operational checkout
Unit information
System reset
System
environment setup
Download
Next
menu
Prev.
menu
Manual
Start
up
Shut
down
Comm
On/Off

Automatic
Adjustment
Back
Status:XXXXXXXXX 2011.07.07 12:45
Proc. status:
 Excitation voltage value [ 1023 ] ( 0 – 1023 )

XXXXXXXXX
XXXXXXXXX XXXXXXXXX
XXXXXXXXX XXXXXXXXX
XXXXXXXXX
XXXXXXXXX
A
djust./oper. checkout
Excitation
adjustment
XXXXXXXXX
