2-35
2.14 Software option setup
- Use this function when setting up software options to IJ printer.
- In order to set up options, EZJ99 board and a memory card (IJP system-data is stored)
are required.
- Perform this function when the IJ printer is in a “Stop” state.
- There are some combinations that cannot be set up simultaneously with other options.
SOP02 SOP03 SOP04 SOP05 SOP08 SOP16-3
SOP02 X X
SOP03 X
SOP04 X
SOP05 X
SOP08 X
SOP16-3 X X X X
X: Combinations that cannot be set up simultaneously with other options
1 Install the EZJ99 board.
2 Turn on the power.
3 Insert the memory card which IJP system-data is stored.
4 Press Option setup at the second page of the service maintenance work
screen.
When Prev.menu and Next menu are not displayed in the maintenance work menu,
set to the service personnel maintenance mode by the password protection.
When a memory card which IJP system-data is stored is not set, Option setup
button is not displayed.
Back
Status:XXXXXXXXX 2011.07.07 12:45Maintenance menu
Solenoid valve/
pump test
Adjustment/
operational checkout
Unit information
Option setup
System reset
System
environment setup
Download
Next
menu
Prev.
menu
Manual
Start
up
Shut
down
Comm
On/Off
With respect to the
password protection, refer
to "2.1 setting of service
personnel maintenance
mode".
To Next Page
