3-2
[Controller part (cover-opening state)]
LCD backlight power supply
EZJ104 board
Touch panel
(operation side)
EZJ97 board
Battery
LCD
(Backside of panel)
Cover fixing screws
(
Two locations
)
Controller part
Cover fixing screws
(
Two locations
)
