[Difference between the EZJ94 board and the EZJ94DH board]
- The red check mark and the blue label are put on the EZJ94DH board for identification.
- The EZJ94 board and the EZJ94DH board are different in resistance of the R125.
How to identify the EZJ94 board and the EZJ94DH board
- Soldered side of the EZJ94DH board
- Numbers typed on the R125 resistance
EZJ94 board EZJ94DH board
* Use a magnifying glass to identify the board because the numbers on the resistance
are small.
The red check mark and the blue
label at the lot number print part.
External view of R125
(Soldered side)
EZJ94 board No
EZJ94DH board Yes
