Field Description
VLAN.
Num of VLANs
mapped
Number of VLANs that are mapped to the MSTI.
Port times
Major parameters for the port:
• Hello—Hello timer.
• MaxAge—Maximum age timer.
• FwdDelay—Forward delay timer.
• MsgAge—Message age timer.
• RemHops—Remaining hops.
BPDU sent Statistics on sent BPDUs.
BPDU received Statistics on received BPDUs.
RegRoot ID/IRPC MSTI regional root/internal path cost.
Root Type
MSTI root type:
• Primary root.
• Secondary root.
Master bridge MSTI root bridge ID.
Cost to master Path cost from the MSTI to the master bridge.
TC received Number of received TC BPDUs.
Protocol status Spanning tree protocol status.
Protocol Std. Spanning tree protocol standard.
Version Spanning tree protocol version.
Bridge-Prio.
• In MSTP mode: Device's priority in the CIST.
• In PVST mode: Device's priority in VLAN 1.
Max age(s)
Aging timer for BPDUs (in seconds, which is the same as the aging timer for VLAN 1
in PVST mode).
Forward delay(s)
Port state transition delay (in seconds, which is the same as the forward delay for
VLAN 1 in PVST mode).
Hello time(s)
Interval for the root bridge to send BPDUs (in seconds, which is the same as the
interval for VLAN 1 in PVST mode).
Max hops Maximum hops in the MSTI.
TC Snooping Status of TC Snooping, which can be
Enabled
or
Disabled
.
Related commands
reset stp
display stp abnormal-port
Use display stp abnormal-port to display information about ports that are blocked by spanning tree
protection functions.
Syntax
display stp abnormal-port
Views
Any view
