Examples
# Display IP subnet-based VLANs on GigabitEthernet 1/0/1.
<Sysname> display ip-subnet-vlan interface gigabitethernet 1/0/1
Interface: GigabitEthernet1/0/1
VLAN ID Subnet index IP address Subnet mask Status
3 0 192.168.1.0 255.255.255.0 Active
4 N/A N/A N/A Inactive
4094 65535 172.16.1.1 255.255.0.0 Inactive
Table 41 Command output
Field Description
VLAN ID ID of the IP subnet-based VLAN.
Subnet index
Index of the IP subnet.
If no IP subnet-based VLAN is configured, this field displays
N/A
.
IP address
IP address of the subnet. It can be an IP address or a subnet address.
If no IP subnet address is configured for the VLAN, this field displays
N/A
.
Subnet mask
Mask of the IP subnet.
If no subnet mask is configured for the VLAN, this field displays
N/A
.
Status
Whether the IP subnet-based VLAN has taken effect on the port:
• Active—The IP subnet-based VLAN has taken effect.
• Inactive—The IP subnet-based VLAN has not taken effect. For example, this
field displays Inactive in one of the following conditions:
{ The configuration of the IP subnet-based VLAN is not complete.
{ The port does not allow the IP subnet-based VLAN.
Related commands
• display ip-subnet-vlan vlan
• ip-subnet-vlan
• port hybrid ip-subnet-vlan
display ip-subnet-vlan vlan
Use display ip-subnet-vlan vlan to display information about IP subnet-based VLANs.
Syntax
display ip-subnet-vlan vlan { vlan-id1 [ to vlan-id2 ] | all }
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
vlan-id1: Specifies an IP subnet-based VLAN by its VLAN ID in the range of 1 to 4094.
vlan-id1 to vlan-id2: Specifies a VLAN ID range. Both the vlan-id1 and the vlan-id2 arguments are in
the range of 1 to 4094. The value for the vlan-id2 argument must be equal to or greater than the
value for the vlan-id1 argument.

HP FlexNetwork 5130 HI series Specifications

General

Model	HP FlexNetwork 5130 HI series
Category	Switch
Switch Type	Managed
Layer	Layer 3
Power over Ethernet (PoE)	Available on some models
Fans	Hot-swappable fans
Management	CLI, Web GUI, SNMP, RMON, HP Intelligent Management Center
Routing Protocol	RIP, OSPF, BGP, IS-IS, Static Routing
Layer 3 Features	VRRP
Security Features	ACLs, IEEE 802.1X, RADIUS, TACACS+, SSH, SSL
Quality of Service (QoS)	DiffServ
Weight	Varies by model
Operating Temperature	0°C to 45°C
VLANs	4094
Operating Humidity	10% to 95% non-condensing
