Configuring the switch 176
Static Multicast Router Configuration for Port
To display the following form, go to the IGMP Static Multicast Router Configuration form. Select an Mrouter Port
number, or open the IGMP Static Mrouter folder and click Add Mrouter.
NOTE: When you configure a static multicast router on a VLAN, the process of learning multicast routers is
disabled for that VLAN.
The following table describes the Static Multicast Router Configuration for Port controls:
Table 144 Static Multicast Router Configuration for Port
Control Description
Mrouter Port ID Selects a port on which the static multicast router is connected.
Note: Port number must be an external port (17-18, 20-24).
Vlan ID Selects a VLAN on which the static multicast router is connected.
IGMP Version? Configures the IGMP version (1 or 2) of the multicast router.
