Dashboard 45
The Flags field is interpreted as follows:
Table 30 ARP Dump Flag Parameters
Flag Description
Interface Permanent entry created for switch IP interface
Indirect Indirect route entry
Unresolved Unresolved ARP entry. The MAC address has not been learned.
Default Gateways Dashboard
To display the following form, select Layer 3 > Default Gateways (click the underlined text, not the folder).
The following table describes the Default Gateways Dashboard controls:
Table 31 Default Gateways Dashboard controls
Control Description
Search Range To search for a Default Gateway, enter a range of Gateway numbers in the From and
To fields.
Search Options To focus the search for a Default Gateway, enter optional search parameters:
• IP Address
• Subnet Mask
• Default Gateway State
Fields that have a value of “any” are ignored during the search.
Choose a search operation:
or: Search for Default Gateways specified in the search range that meet any of the
criteria entered.
and: Search for Default Gateways specified in the search range that meet all of the
criteria entered.
Click Search to display Default Gateways that fit the range and meet the criteria
entered.
Status Shows if the Default Gateway is enabled (green) or disabled (red).
Default Gateway ID Displays the numeric identifier of the Default Gateway.
IP Address Displays the IP Address of the Default Gateway.
