Dashboard 51
OSPF Virtual Links Dashboard
NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > OSPF > Virtual Links (click the underlined text, not the folder).
The following table describes the OSPF Virtual Links Dashboard controls:
Table 37 OSPF Virtual Links Dashboard controls
Control Description
Virtual Link Displays the virtual link number.
Enabled? Displays the status of the virtual link, either Enabled or Disabled.
Area Number Displays the area number associated with the virtual link.
Neighbor Router ID Displays the neighbor router ID.
Transit Delay Displays the transit delay value, in seconds.
RIP General Information
NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > RIP > General.
The following table describes the Routing Information Protocol (RIP) General Information controls:
Table 38 RIP General Information controls
Control Description
Global RIP Enabled State Displays the global state of RIP: enabled or disabled.
Update Period (sec) Displays the time interval for sending for RIP table updates.
