Configuring the switch 204
ACL Metering Configuration
To display the following form, go to the ACL Configuration Table form, and select an ACL number, or open the
Access Control Lists folder and click Add ACL.
The following table describes the ACL Metering Configuration controls:
Table 171 ACL Metering Configuration controls
Control Description
Committed rate
(64 - 1000000 kb/s)
Configures the committed rate, in Kilobits per second. The committed rate must be a multiple
of 64.
Maximum burst Size
(32 - -4096 kb/s)
Configures the maximum burst size, in Kilobits. Enter one of the following values for
mbsize: 32, 64, 128, 256, 512, 1024, 2048, 4096
Set out of profile to Drop or
Pass
Configures the ACL Meter to either drop or pass out-of-profile traffic.
Enable Enables or disables the ACL meter.
