Dashboard 19
Table 3 Switch Dashboard controls
Control Description
Daylight Savings Location Displays the time zone where the switch resides. You are prompted to select your
location (continent, country, region) by the timezone wizard. Once a region is selected,
the switch updates the time to reflect local changes to Daylight Savings Time, etc.
MAC Address Displays the MAC Address of the switch management processor.
IP Address Displays the IP address of IP Interface 1.
Hardware Revision Displays the hardware revision number of the switch.
Switch Serial No Displays the serial number of the switch.
Hardware Part No Displays the part number of the switch hardware.
HW Spare Part No Displays the part number of spare switch hardware.
Software Rev Displays the software revision number.
Banner Displays the login banner text. When a user or administrator logs into the switch, the
login banner is displayed.
It is also displayed as part of the output from the
/info/sys/gen command.
User Access Dashboard
To display the following form, select System > User Table.
The following table describes the User Access Dashboard controls:
Table 4 User Access Dashboard controls
Control Description
User ID Displays the numeric identifier for the user
User Name Displays the name of the user.
COS Displays the Class of Service level for the user.
Password Indicates whether a valid password is defined for the user.
Status Displays whether the user is enabled or disabled.
Login Displays the login status of the user (online or offline).
