Configuring the switch 180
OSPF Summary Ranges Configuration
NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > OSPF Routing Protocol > OSPF Summary Ranges (click the
underlined text, not the folder).
This form provides a summary of the state of OSPF summary ranges.
OSPF Summary Range Configuration
NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, go to the OSPF Summary Ranges Configuration form. Select a summary range
number, or open the OSPF Summary Ranges folder and click Add Summary Range.
The following table describes the OSPF Summary Range Configuration controls:
Table 148 OSPF Summary Range Configuration controls
Control Descriptions
Range Number (1-16) Assigns a numeric identifier to the OSPF summary range.
Enabled? Enables or disables the OSPF summary range.
Hide Range Hides or shows the OSPF summary range.
Area number (0-2) Defines the area index used by the switch.
IP Address Defines the base IP address for the range.
