Dashboard 60
Uplink Failure Detection Dashboard
To display the following form, select Uplink Failure Detection (click the underlined text, not the folder).
The following table describes the Uplink Failure Detection Dashboard controls:
Table 43 Uplink Failure Detection Dashboard controls
Control Description
UFD State Displays the global status of Uplink Failure Detection.
FDP State Displays whether the Failure Detection Pair is enabled or disabled.
LtM status Displays the current status of the Link to Monitor (LtM).
LtD status Displays the current status of the Link to Disable (LtD).
LtM Ports Displays the link status and Spanning Tree information for each port in the LtM.
LtD Ports Displays the link status for each port in the LtD.
