RIP Interfaces Dashboard
NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > RIP > RIP Interfaces (click the underlined text, not the folder).
The following table describes the RIP Interfaces Dashboard controls:
Table 39 RIP Interfaces Dashboard controls
Control Description
Search Range To search for a RIP interface, enter a range of interface ID numbers in the
From and To fields.
Search Options To focus the search for a RIP interface, enter optional search parameters:
• RIP version
• RIP state
Fields that have a value of “any” are ignored during the search.
Choose a search operation:
• or: Search for RIP interfaces specified in the search range that meet any
of the criteria entered.
• and: Search for RIP interfaces specified in the search range that meet all
of the criteria entered.
Click Search to display RIP interface that fit the range and meet the criteria
entered.
Interface ID Displays each interface number.
RIP State Displays the current status of RIP in the interface: enabled or disabled.
RIP Version Displays the RIP version used by the interface.
Default Action Displays the default action for RIP on the interface.
Supply Updates Displays the current status of Supply: enabled or disabled.
Listen to Updates Displays whether Supply Updates is enabled or disabled.
Poisoned Reverse Displays whether Poisoned Reverse is enabled or disabled.
Triggered Updates Displays whether Triggered Updates is enabled or disabled.
Multicast Updates Displays whether Multicast Updates is enabled or disabled.
Metric Displays the route metric for the interface.
Auth Type Displays the authentication type for the interface.
