Configuring the switch 185
The following table describes OSPF Hosts Configuration controls:
Table 152 OSPF Hosts Configuration controls
Control Description
Search Operation To focus the search for an OSPF host, enter search parameters:
• Host ID
• IP address and subnet mask
• Area number
• State
Fields that have a value of “any” are ignored during the search.
Choose a search operation:
• or: Search for OSPF hosts specified in the Search range that meet any of the criteria
entered.
• and: Search for OSPF hosts specified in the Search range that meet all of the criteria
entered.
Click Search to display OSPF hosts that fit the range and meet the criteria entered.
OSPF Host Configuration
NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, go to the OSPF Hosts Configuration form. Select a host number, or open the OSPF
Hosts folder and click Add OSPF Host.
The following table describes the OSPF Host Configuration controls:
Table 153 OSPF Host Configuration controls
Control Descriptions
Host Identifier (1-128) Assigns a numeric identifier to the OSPF host.
IP Address Defines the base IP address for the host entry.
Enabled? Enables or disables the OSPF virtual link.
Area Number (0-2) Defines the area index used by the OSPF host.
Output Cost (1-65535) Defines the cost value of the host.
