HP MSR4080 User Manual

9
Examples
# Display the path that the packets traverse from source to destination (1.1.2.2).
<Sysname> tracert 1.1.2.2
traceroute to 1.1.2.2 (1.1.2.2), 30 hops at most, 40 bytes each packet, press CTRL_C to
break
1 1.1.1.2 (1.1.1.2) 673 ms 425 ms 30 ms
2 1.1.2.2 (1.1.2.2) 580 ms 470 ms 80 ms
# Trace the path to destination (192.168.0.46) over an MPLS network.
<Sysname> tracert 192.168.0.46
traceroute to 192.168.0.46(192.168.0.46), 30 hops at most, 40 bytes each packet, press
CTRL_C to break
1 192.0.2.13 (192.0.2.13) 0.661 ms 0.618 ms 0.579 ms
2 192.0.2.9 (192.0.2.9) 0.861 ms 0.718 ms 0.679 ms
MPLS Label=100048 Exp=0 TTL=1 S=1
3 192.0.2.5 (192.0.2.5) 0.822 ms 0.731 ms 0.708 ms
MPLS Label=100016 Exp=0 TTL=1 S=1
4 192.0.2.1 (192.0.2.1) 0.961 ms 8.676 ms 0.875 ms
Table 3 Command output
Field Descri
p
tion
traceroute to 1.1.2.2 (1.1.2.2)
Display the route that the IP packets traverse from the current device to the
device whose IP address is 1.1.2.2.
hops at most
Maximum number of hops of the probe packets, which can be set by the -m
keyword.
bytes each packet Number of bytes of a probe packet.
press CTRL_C to break
During the execution of the command, press Ctrl+C to abort the tracert
operation.
1 1.1.1.2 (1.1.1.2) 673 ms
425 ms 30 ms
Probe result of the probe packets whose TTL is 1, including the following:
• Domain name (or IP address, if the domain name is not configured) of the
first hop.
• The round-trip time of the three probe packets.
The number of packets that can be sent in each probe can be set through the
-q keyword.
MPLS Label=100048 Exp=0
TTL=1 S=1
ICMP timeout packets on an MPLS network, carrying MPLS label information:
• Label—Label value that is used to identify a forwarding equivalence class
(FEC).
• Exp—Reserved, usually used for class of service (CoS).
• TTL—TTL value.
• S—MPLS supports multiple levels of labels. Value 1 indicates that the label
is at the bottom of the label stack, and value 0 indicates that the label is in
another label stack.
tracert ipv6
Use tracert ipv6 to display the path that the IPv6 packets traverse from source to destination.
