Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
5 NE40E-8 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
135
Component
Description
CF ACT indicator
(red)

If the indicator is blinking, the data is being received or
transmitted.

If the indicator is off, no data is being received or transmitted.
NOTE
The CF card is not hot swappable.
LINK indicator (green)
(on the Ethernet
interface)

If the indicator is on, the link is Up.

If the indicator is off, the link is Down.
ACT indicator
(yellow) (on the
Ethernet interface)

If the indicator is off, no data is being received or transmitted.

If the indicator is blinking, the data is being received or
transmitted.
Interface Functions
Table 5-13 lists the functions of the interfaces on the SRU.
Table 5-13 Functions of the interfaces on the SRU
Interface Name
Connector Type
Description
ETH0
(10M/100M/1000M
Base-TX
auto-sensing)
RJ45
Used to connect the system network
workstation. This interface has the LINK
and ACT indicators.
Console interface
RJ45
Used to connect the console for system
configuration.
AUX interface
RJ45
Used to connect to the modem for
remote maintenance through dialing.
CF interface
TYPE II standard
(TYPE I standard is
compatible)
Used to save data files as a massive
storage device.
CLK-IN1
SMB (Sub-miniature B)
Used to receive the external clock signal
of 2.048 MHz or 2.048 Mbit/s.
CLK-IN2
CLK-OUT1
SMB
Used to output the 2.048 MHz or 2.048
Mbit/s clock signal to the downstream
device.
CLK-OUT2
Table 5-14lists the functions of the interfaces on the SRU that supports the 1588v2 protocol.
