Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
372
Indicator
Description
indicator(green)
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-304 lists the interface attributes of the 1-port OC-192c/STM-64c POS-XFP FPIC.
Table 6-304 Interface attributes of the 1-port OC-192c/STM-64c POS-XFP FPIC
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected XFP optical module. (for the attributes of
XFP modules, see Table 6-305)
Working mode
Full-duplex
Frame format
PPP or HDLC
Network
protocol
IP
Table 6-305 Attributes of 10G XFP optical modules
Attributes
Description
Maximum
transmission
distance
10 km ( 6.21 mi. )
40 km ( 24.86 mi. )
80 km ( 49.71 mi. )
Center wavelength
1310 nm
1550 nm
1550 nm
Minimum
transmitting
power
-6.0 dBm
-1.0 dBm
0 dBm
Maximum
transmitting
power
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload optical
power
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber type
Single-mode
Single-mode
Single-mode
