Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
391
Component
Description
LINK/ACT
indicator(green)
If the indicator is on, the link is Up.
If the indicator is blinking, the data is being read or written.
If the indicator is off, the link is Down.
Interface Attributes
Table 6-335 lists the interface attributes of the 20-Port 100/1000Base-X-SFP Flexible Card B.
Table 6-335 Interface attributes of the 20-Port 100/1000Base-X-SFP Flexible Card B
Attributes
Description
Connector type
LC/PC
Optical interface
attributes
Compliant with the selected SFP optical module.
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol
IP
Table 6-336 Attributes of 100M SFP optical modules
Attributes
Description
Maximum
transmission
distance
2 km ( 1.24
mi. )
15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center wavelength
1310 nm
1310 nm
1310 nm
1550 nm
Minimum
transmitting power
-19.0 dBm
-15.0 dBm
-5.0 dBm
-5.0 dBm
Maximum
transmitting power
-14.0 dBm
-8.0 dBm
0 dBm
0 dBm
Receiving
sensitivity
-30.0 dBm
-31.0 dBm
-37.0 dBm
-37.0 dBm
Overload optical
power
-14.0 dBm
-8.0 dBm
-10.0 dBm
-10.0 dBm
Optical fiber type
Multi-mode
Single-mode
Single-mode
Single-mode
