Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
398
Attributes
Description
Maximum
transmitting
power
-1.3 dBm
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-7.5 dBm
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload
optical power
-1.0 dBm
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical module supports two types of multi-mode optical fibers
with different cores. Table 6-349 shows the relationship between the core, the
modal/bandwidth, and the transmission distance. During configuration, the length of optical
fibers is restricted by the transmission distance. In addition, the optical fiber with the 50-um
core and 2000-MHz*km modal/bandwidth is a special type, which is not delivered by
Huawei.If this type of optical fiber is required, you need to purchase it additionally.
Table 6-349 The transmission distance of 10G XFP optical modules
Core(μm)
Modal/Bandwidth(Mhz*
km)
Transmission Distance
(km)
50
2000
2-300 ( 1.24 - 186.42 )
50
500
2-82 ( 1.24 - 50.95 )
62.5
200
2-33 ( 1.24 - 20.51 )
Technical Specifications
Table 6-350 lists the technical specifications of the 2-Port 10GBase LAN/WAN-XFP Flexible
Card A(Supporting 1588v2).
Table 6-350 Technical specifications of the 2-Port 10GBase LAN/WAN-XFP Flexible Card
A(Supporting 1588v2)
Item
Specifications
Silkscreen of the
board name
P40-2x10GBase LAN/WAN-XFP-A
Power consumption
(typical value)
About 27 W
Heat dissipation
88 BTU/hour
Board weight
About 0.61 kg ( 1.35 lb )
