Interface Attributes
Table 6-387 lists the interface attributes of the 4-port 10GBase LAN/WAN-XFP Integrated
Line Processing Unit.
Table 6-387 Interface attributes of the 4-port 10GBase LAN/WAN-XFP Integrated Line
Processing Unit
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected XFP optical module. (For the attributes of
XFP modules, see Table 6-388)
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-388 Attributes of 10G XFP optical modules
Attributes
Description
Transmission
distance
0.3 km ( 0.19
mi. )
10 km ( 6.21
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center
wavelength
850 nm
1310 nm
1550 nm
1550 nm
Minimum
transmitting
power
-7.3 dBm
-6.0 dBm
-1.0 dBm
0 dBm
Maximum
transmitting
power
-1.3 dBm
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-7.5 dBm
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload
power
-1.0 dBm
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical transceiver supports two types of multi-mode optical fibers
with different cores. Table 6-389 lists the relationship between the core, the modal/bandwidth,
and the transmission distance. During configuration, the length of optical fibers is restricted
by the transmission distance. In addition, the optical fiber with the 50-um core and
