Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
542
Table 6-571 Interface attributes of the 40-port 100/1000Base-SFP FPIC
Attributes
Description
Connector type
LC/PC
Optical interface
attributes
Compliant with the selected SFP optical module
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol
IP
Table 6-572 Attributes of 100M SFP optical modules
Attributes
Description
Maximum
transmission
distance
2 km ( 1.24
mi. )
15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center wavelength
1310 nm
1310 nm
1310 nm
1550 nm
Minimum
transmitting power
-19.0 dBm
-15.0 dBm
-5.0 dBm
-5.0 dBm
Maximum
transmitting power
-14.0 dBm
-8.0 dBm
0 dBm
0 dBm
Receiving
sensitivity
-30.0 dBm
-31.0 dBm
-37.0 dBm
-37.0 dBm
Overload optical
power
-14.0 dBm
-8.0 dBm
-10.0 dBm
-10.0 dBm
Optical fiber type
Multi-mode
Single-mode
Single-mode
Single-mode
Table 6-573 Attributes of 1000M SFP optical modules
Attributes
Description
Maximum
transmission
distance
0.5 km
( 0.31
mi. )
10 km
( 6.21
mi. )
40 km
( 24.86
mi. )
40 km
( 24.86
mi. )
80 km
( 49.71
mi. )
100 km
( 62.14
mi. )
Center
wavelength
850 nm
1310 nm
1310 nm
1550 nm
1550
nm
1550 nm
Minimum
transmitting
power
-9.5 dBm
-9.5 dBm
-4.5 dBm
-4.0 dBm
-2.0
dBm
0 dBm
Maximum
-2.5 dBm
-3.0 dBm
3.0 dBm
1.0 dBm
5.0
5.0 dBm
