Eserver pSeries 670 Physical Specifications and Loads
The following tables illustrate the physical, electrical and thermal, as well as acoustical and environmental
characteristics of various Eserver pSeries 670 system configurations.
Dimensions and Weight
Physical Characteristic Slimline Doors Acoustical Doors
Height 2025 mm (79.72 in.) 2025 mm (79.72 in.)
Width 785 mm (30.91 in.) 785 mm (30.91 in.)
Depth 1342 mm (52.83 in.) 1494 mm (58.83 in.)
Weight (maximum configuration) 1085 kg (2392 lbs.) 1099 kg (2422 lbs.)
Note: When moving or relocating certain configurations of the system, the Bulk Power Regulators (BPRs) must be
removed from the top of the rack (front and rear) to ensure product stability. Specifically, removal of the BPR from the
front and rear is required in systems that have a single I/O drawer.
System Weights by Configuration
Total System Weight (Pounds)
1 I/O Subsystem 2 I/O Subsystems 3 I/O Subsystems
Slimline Doors With IBF 2062 2227 2392
Slimline Doors Without IBF 1865 2030 2195
Acoustical Doors With IBF 2092 2257 2422
Acoustical Doors Without IBF 1923 2088 2253
No Doors With IBF 2004 2169 2334
No Doors Without IBF 1807 1972 2137
Total System Weight (Kilograms)
1 I/O Subsystem 2 I/O Subsystems 3 I/O Subsystems
Slimline Doors With IBF 935 1010 1085
Slimline Doors Without IBF 846 921 996
Acoustical Doors With IBF 949 1024 1099
Acoustical Doors Without IBF 872 947 1022
No Doors With IBF 909 984 1059
No Doors Without IBF 820 894 969
Chapter 2. Physical Characteristics of Systems 135
