7013 Models J30, J40, and J01
Dimensions J30 & J40 J01
Height 610 mm 24 in. 610 mm 24 in.
Width 360 mm 14.2 in. 360 mm 14.2 in.
Depth 750 mm 29.5 in. 750 mm 29.5 in.
Weight J30 & J40 J01
Minimum 67 kg 148 lbs. 67 kg 148 lbs.
Maximum 84 kg 185 lbs. 84 kg 185 lbs.
Electrical J30 & J40 J01
Power source loading 0.9 0.6
(typical in kVA)
Voltage range (V ac) 100 to 125 or 200 to 100 to 125 or 200 to
240 (autoranging) 240 (autoranging)
Frequency (hertz) 50 or 60 50 or 60
Thermal output (typical) 2765 Btu/hr 1843 Btu/hr
Power requirements (typical) 810 watts 540 watts
Power factor 0.8 to 1.0 0.8 to 1.0
Inrush current³ 35 amps at 120 V ac 35 amps at 120 V ac
70 amps at 240 V ac 70 amps at 240 V ac
Maximum altitude 2500 m (8202 ft.) 2500 m (8202 ft.)
Temperature Requirements Operating
10 to 32°C
(50 to 90°F)
Non-Operating
5 to 50°C
(41 to 122°F)
Humidity (Noncondensing) Operating Non-Operating
Without tape drive 8 to 80% 5 to 95%
With tape drive 20 to 80% 20 to 80%
Wet Bulb Requirements
Without tape drive 24°C (75°F) 28°C (82°F)
With tape drive 23°C (73°F) 27°C (80°F)
Noise Emissions
1,4
Operating Idle
L
WAd
5.8 bels 5.5 bels
L
pAm
N/A N/A
<L
pA
>
m
NA NA
Impulsive or prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 500mm(20 in) 500mm(20 in) 500mm(20 in) 500mm(20 in)
Service 500mm(20 in) N/A N/A N/A
Footprint
2
Width
1630mm(64 in)
Depth
1750mm(70 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
26 Site and Hardware Planning Information
