7135 RAIDiant Array Deskside Mini-Rack
Dimensions
Height 610 mm 24.0 in.
Width 560 mm 23.1 in.
Depth 750 mm 29.5 in.
Weight
Empty 54.5 kg 120 lbs.
Maximum
Configuration
177.0 kg 390 lbs.
Electrical¹
,
³
Power source loading
(kVA)
0.2 plus 0.03 for each disk drive
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output (max) 648 Btu/hr plus 92 Btu/hr for each disk drive
Power requirements
(max)
190 watts plus 27 watts for each disk drive
Power factor 0.95
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20% to 80% 8% to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions
2,3
Operating Idle
L
WAd
N/A 0 bels
L
pAm
N/A N/A
<L
pA
>
m
N/A 0 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 1 m(39.4 in) 1 m(39.4 in) N/A 1 m(39.4 in)
1. The Mini-Rack has a 10A fuse, these values indicate the maximum values for the Mini-Rack with installed
devices. The actual values depend on which devices are installed.
2. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
3. Dependant on the devices installed in the 7135 Mini-Rack.
Chapter 7. Physical Characteristics of the 7100 Series 275
