7012 Models G30, G40, and G02
Dimensions G30 & G40 G02
Height 450 mm 17.75 in. 450 mm 17.75 in.
Width 173 mm 6.9 in. 173 mm 6.9 in.
Width (at pedestal) 280 mm 11 in. 280 mm 11 in.
Depth 613 mm 24.1 in. 613 mm 24.1 in.
Weight G30 & G40 G02
Minimum 19 kg 43 lbs. 19 kg 43 kg
Maximum 25 kg 55 lbs. 25 lbs. 55 lbs.
Electrical G30 & G40 G02
Power source loading (typical in
kVA)
0.45 0.2
Voltage range (V ac) 100 to 125 or 200 to 100 to 125 or 200 to
240 (autoranging) 240 (autoranging)
Frequency (hertz) 50 or 60 50 or 60
Thermal output (typical) 1380 Btu/hr 615 Btu/hr
Power requirements (typical) 405 watts 180 watts
Power factor 0.8 to 1.0 0.8 to 1.0
Inrush current³ 35 amps at 120 V ac 35 amps at 120 V ac
70 amps at 240 V ac 70 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.) 2135 m (7000 ft.)
Temperature Requirements Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity Requirements Operating Non-Operating
(Noncondensing)
Without tape drive 8 to 80% 8 to 80%
With tape drive 20 to 80% 20 to 80%
Wet Bulb Requirements
Without tape drive 27°C (80°F) 27°C (80°F)
With tape drive 23°C (73°F) 27°C (80°F)
Noise Emissions¹ Operating Idle
L
WAd
5.8 bels 5.5 bels
L
pAm
39 dBA 37 dBA
<L
pA
>
m
39 dBA 37 dBA
Impulsive or prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow² 152 mm(6 in) 152 mm(6 in) N/A N/A
Service 760 mm(30 in) N/A N/A N/A
Footprint
2
Width
280mm(11 in)
Depth
917mm(36.1 in)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
Chapter 2. Physical Characteristics of Systems 21
