7014 Rack
Model T00 Rack
Dimensions
Height 1804 mm 71.0 in.
Capacity 36 EIA Units
With PDP - DC only 1926 mm 75.8 in.
Width without side
panels
623 mm 24.5 in.
With side panels 644 mm 25.4 in.
Depth with rear door
only
1042 mm 41.0 in.
Depth with rear door
and RS/6000 style
front door
1098 mm 43.3 in.
pSeries (sculptured)
style front door
1147 mm 45.2 in.
Weight
Base Rack 244 kg 535 lbs
Full Rack¹ 816 kg 1795 lbs
See “T00 and T42 Rack Weight Distribution and Floor Loading” on page 35.
Electrical² (sum specified values for
drawers or enclosures in rack)
DC Rack
Power source loading
maximum in kVA³
8.4
Voltage range (V dc) -40 to -60
AC Rack
Power source loading
maximum in kVA (per
PDB)⁴
4.8
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Temperature
Requirements
(see specifications for drawers or enclosures)
Humidity
Requirements
(see specifications for drawers or enclosures)
Noise Emissions (see specifications for drawers or enclosures)
Clearances Front Back Left Right
Install/Air Flow Rack airflow requirements are a function of the number and type of drawers installed (see 5
on page 32). Refer to the individual drawer specifications.
Service 915mm(36 in) 915mm(36 in) 915mm(36 in) 915mm(36 in)
Chapter 2. Physical Characteristics of Systems 31
