7334 Model 410 8-mm Tape Library
Dimensions
Height 220.0 mm 8.7 in.
Width 438.0 mm 17.2 in.
Depth 612.0 mm 24.1 in.
Weight
Minimum 34.5 kg 76 lbs.
Maximum 34.5 kg 76 lbs.
Electrical
Power source loading
(kVA)
0.03
Voltage range (V ac) 100 to 125 or 200 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output 427 Btu/hr
Power requirements 125 watts
Power factor 0.3 to 0.6
Maximum altitude 3048 m (10,000 ft.)
Temperature
Requirements
Operating
5 to 35°C
(41 to 95°F)
Non-Operating
–20 to 60°C
(–4 to 140°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20% to 80% 10% to 90%
Wet Bulb 26°C (79°F) 29°C (84°F)
Noise Emissions* Operating Idle
L
WAd
6.3 bels 5.8 bels
L
pAm
N/A N/A
<L
pA
>
m
46 dBA 43 dBA
Impulsive or
prominent discrete
tones
No No
* See “Noise Emission Notes” on page 336 for definitions of emissions positions
322 Site and Hardware Planning Information
