7026 Model H10 Drawer
Dimensions
Height 306.2 mm 12.1 in.
Width 442.4 mm 17.4 in.
Depth 748.2 mm 29.5 in.
Weight
Minimum configuration 42 kg 92 lbs.
Maximum configuration 57 kg 126 lbs.
Electrical
Power source loading 0.41
(typical in kVA)
Power source loading 0.56
(maximum in kVA)
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Thermal output (typical) 683 Btu/hr
Thermal output (maximum) 1365 Btu/hr
Power requirements (typical) 200 watts
Power requirements (maximum) 400 watts
Power factor 0.8 - 0.96
Inrush current³ 60 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature Requirements Operating
10 to 40°C
(50 to 104°F)
Non-Operating
10 to 52°C
(50 to 125.6°F)
Humidity (Noncondensing) Operating Non-Operating
Without tape drive 8 to 80% 8 to 80%
With tape drive 20 to 80% 20 to 80%
Wet Bulb Requirements
Without tape drive 27°C (80°F) 27°C (80°F)
With tape drive 23°C (73°F) 27°C (80°F)
Noise Emissions
1,2
Operating Idle
L
WAd
5.9 bels 5.8 bels
L
pAm
N/A N/A
<L
pA
>
m
39 dBA 38 dBA
Impulsive or prominent discrete tones No No
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper air flow.
Service (See service clearances for the “7015 System Rack R00” on page 41)
1. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
2. Noise emissions data for the Model H10 CPU Drawer is based on the processor drawer mounted in a “7015
System Rack R00” on page 41.
3. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
74 Site and Hardware Planning Information
